Description
- 6 Aerodynamic Polymer Blades
- 9 Speed DC Remote Control Included
- DC Energy Efficient Motor
- Pixie & WIFI Adaptable (Sold Separately)
Installation Locations
Coastal, indoor and outdoor locations. The fan is also suitable for installation in a pergola or outside in a sheltered area, protected from wind
Standard Canopy Cover
Suitable for flat ceilings only. An accessory 38 Degree Canopy Kit can be purchased separately for installation on raked ceiling up to 38°
Recommended Height
There should be at least 2.1m between the lowest point of the fan blades and the floor.
Motor
156mm x 10mm DC motor
Made with high grade copper windings and silicone steel stator. Bearings are sealed to ensure quiet operation and long life.
Top Canopy & Downrod
Materials: ABS & Steel
Product Range
M800 - White with White Blades
M801 - Matt Black with Black Blades
Blades
Sizes: 2030mm (80”)
Materials: ABS Polymer, UV stabilised
Blade Pitch: 7.5°
Accessories (Supplied separately)
THD Down Rod 26mm diameter (includes wire harness)
DC2480 - 91cm White Downrod
DC2481 - 91cm Black Downrod
DC2490 - 180cm White Downrod
DC2491 - 180cm Black Downrod
38° Ceiling Kit (for pitched ceilings)
080 - Ceiling Kit White 38°
082 - Ceiling Kit Painted Silver 38°
083 - Ceiling Kit Black 38°
009 - T-Hook for ceiling roses
DCWC240 - 240V DC Wall Controller
WIFIM099 - Smart WiFi Module
PIXIE098 - Pixie HPI Ceiling Fan Module
Extra Information
9 Speed remote controller Reversible
Airflow CMH
22,328 on High speed (Speed 9)
Warranty*
2 years in-home warranty on all electric components
(control modules, remote control system, lighting and accessory wall control)
3 years standard “in home” warranty
3 years extended warranty on motor only (excluding labour)
Dimensions
- Diameter: 2030mm (80")
- Height: 310mm
Click here to view technical specifications:
