Description
The HV9795-IP67-200-SPIRGB-20M Side Bend Chasing RGB LED Strip delivers vibrant, dynamic colour effects with programmable chasing sequences.
Supplied in a 20-metre length, its flexible side-bending design follows curves and contours, making it ideal for architectural features, signage and creative decorative lighting.
Operating at 20W per metre on 24V DC, its IP67 construction is suitable for indoor and outdoor installations.
Specifications
- Input Voltage: 24V DC power supply required (not included)
- Wattage: 20W
- Colour Temp: RGB (Chasing)
- Lumens: 405lm
- Beam Angle: 120°
- Bending Radius: 60mm
- IP Rating: IP67
- PCB: 3oz
- CRI: >90
- Wiring: Parallel
- Dimmable: Yes
- LED Chip Type: 2835
- No. Chips Per Metre: 84
- Maximum Length: 5000mm
- Cutting Increments: Every 83.3mm
- Mounting: Mounting Clips (4x Supplied Per Metre)
- Operating Temperature: 0 to +60° Celcius
- Ambient Temperature: -20° to +50° Celcius
- Warranty: 3 Years Replacement*
Dimensions
- Length: 20000mm
- Width: 12mm
- Height: 17mm
Click to view technical specifications:
