Usually leaves our warehouse in 3-4 business days
Description
- 3 Speed wall control (mechanical only)
- Summer/Winter reversible via switch on motor
- Polymer tapered blades
- Remote Adaptable
- Suitable for pitched ceilings up to 28°
- Acrylic diffuser
- 7 Year warranty^
Installation Locations
- Indoor, coastal and outdoor undercover (provided the fan is fully undercover). Also suitable for installation in a pergola or outside in a sheltered area, protected from wind and rain.
- There should be at least 2.1m between the lowest point of the fan blades and the floor.
Wall Control Speed Capacitor Values
- 3.5μF & 2μF
Light Fitting
- 2 x E27 lamp holders (bulbs not included)
Accessories (Supplied separately)
Down Rod 26mm diameter (includes wire loom)
- 010 - 910mm White Downrod
- 020 - 180cm White Downrod
38° Ceiling Kit (for pitched ceilings)
- 080 - Ceiling Kit White
- 009 - T-Hook for ceiling roses
AC Remote Control Units
- A2002 - Konetik (3 speed - non dimming AC remote)
- A2003 - Logic (4 speed - dimming, timer function, AC remote)
Zellweger Ripple Tone Filter Unit
- 007 - 1050Hz Notch Filter Noise Suppressor
- 008 - 750Hz Notch Filter Noise Suppressor
- W06-015 Capacitor 2 & 3.5uF
- W06-018 Wall Mech & Knob Only
- W06-023 Start Run Cap 1.8uF
- W06-026 Wall Mech & Capacitor 2 & 3.5uF
Extra Information
Motor: 153mm x 15mm 16 Poles AC motor
Made with high grade copper windings and silicone steel stator. Bearings are sealed to ensure quiet operation and long life.
Blades: 132cm (52”)
- Materials: Polymer
- Blade Pitch: 11°
Dimensions
- Width: 1320mm
- Height: 432mm
- Canopy Diameter: 173mm
Click to view technical specification:
- Summer/Winter reversible via switch on motor
- Polymer tapered blades
- Remote Adaptable
- Suitable for pitched ceilings up to 28°
- Acrylic diffuser
- 7 Year warranty^
Installation Locations
- Indoor, coastal and outdoor undercover (provided the fan is fully undercover). Also suitable for installation in a pergola or outside in a sheltered area, protected from wind and rain.
- There should be at least 2.1m between the lowest point of the fan blades and the floor.
Wall Control Speed Capacitor Values
- 3.5μF & 2μF
Light Fitting
- 2 x E27 lamp holders (bulbs not included)
Accessories (Supplied separately)
Down Rod 26mm diameter (includes wire loom)
- 010 - 910mm White Downrod
- 020 - 180cm White Downrod
38° Ceiling Kit (for pitched ceilings)
- 080 - Ceiling Kit White
- 009 - T-Hook for ceiling roses
AC Remote Control Units
- A2002 - Konetik (3 speed - non dimming AC remote)
- A2003 - Logic (4 speed - dimming, timer function, AC remote)
Zellweger Ripple Tone Filter Unit
- 007 - 1050Hz Notch Filter Noise Suppressor
- 008 - 750Hz Notch Filter Noise Suppressor
- W06-015 Capacitor 2 & 3.5uF
- W06-018 Wall Mech & Knob Only
- W06-023 Start Run Cap 1.8uF
- W06-026 Wall Mech & Capacitor 2 & 3.5uF
Extra Information
Motor: 153mm x 15mm 16 Poles AC motor
Made with high grade copper windings and silicone steel stator. Bearings are sealed to ensure quiet operation and long life.
Blades: 132cm (52”)
- Materials: Polymer
- Blade Pitch: 11°
Dimensions
- Width: 1320mm
- Height: 432mm
- Canopy Diameter: 173mm
Click to view technical specification:
