Description
The HV9783-IP20-252-5K-5M is an ultra high-performance 5 metre roll of 46W per metre LED Strip designed to deliver exceptionally bright 5500K Cool White illumination for demanding architectural, commercial, and retail lighting applications.
Featuring 252 high-output LEDs per metre, it produces outstanding brightness with smooth, uniform light distribution, making it ideal for premium linear lighting installations where maximum illumination is required.
Operating on 24V DC, this flexible LED strip is perfect for under-cabinet lighting, shelving, joinery, cove lighting, retail displays, hospitality venues, commercial interiors, task lighting, and feature lighting projects. For optimum performance and heat dissipation, it is recommended for installation in compatible aluminium LED profiles.
Specifications
- Input Voltage: 24V DC power supply required (not included)
- Wattage: 46W
- Colour Temp: 5500K
- Lumens: 4600lm
- IP Rating: IP20
- Beam Angle: 120°
- PCB: 3oz
- CRI: >80
- Lamp Expectancy: >50000hrs
- Wiring: Parallel
- Dimmable: Yes
- LED Chip Type: 2835
- No. of Chips Per Metre: 252
- Maximum Cut Length: 3000mm
- Cutting Increments: 83mm
- Mounting: Aluminium Profile or Heat Sink
- Operating Temperature: 0 - +60° Celsius
- Ambient Temperature: -20° - +50° Celsius
- Warranty: 3 Years Replacement
Dimensions
- Length: 5000mm
- Width: 39mm
- Height: 1.9mm
Click to view technical specifications:
