Description
The HV9731-IP20-180-3K-30M Micro LED Strip is supplied in a convenient 30-metre roll, delivering smooth and uniform warm white illumination for larger indoor lighting projects.
Featuring 180 micro LEDs per metre, it provides a refined lighting effect with minimal visible hotspots, making it ideal for cabinetry, shelving, display cases, cove lighting, decorative features, and architectural lighting applications.
Its ultra-slim, flexible design and IP20 rating make it perfect for dry indoor environments and installation in aluminium profiles or concealed lighting channels.
Specifications
- Input Voltage: 24V DC power supply required (not included)
- Wattage: 4.8W
- Colour Temp: 3000K
- Lumens: 390lm
- Beam Angle: 120°
- IP Rating: IP20
- PCB: 3oz
- CRI: >80
- Lamp Expectancy: >50000hrs
- Wiring: Parallel
- Dimmable: Yes
- LED Chip Type: 2216
- LEDs per Metre: 180
- Maximum Length: 5000mm
- Cutting Increments: 33mm
- Mounting: Aluminium Profile or Heat Sink
- Operating Temperature: 0 - +60° Celcius
- Ambient Temperature: -20° - +50° Cecius
- Warranty: 3 Years Replacement*
Dimensions
- Length: 30000mm
- Width: 4mm
- Height: 0.8mm
