Description
The HV9731-IP20-180-3K Micro LED Strip delivers smooth and uniform warm white illumination using 180 micro LEDs per metre for a refined lighting effect with minimal visible hotspots.
Its ultra-slim, flexible design makes it ideal for cabinetry, shelving, display cases, cove lighting, decorative features, and other precision indoor lighting applications.
With an IP20 rating, it is designed for dry indoor environments and is perfect for installation in aluminium profiles or concealed lighting channels.
Specifications
- Input Voltage: 24V DC power supply required (not included)
- Wattage: 4.8W
- Colour Temp: 3000K
- Lumens: 390lm
- Beam Angle: 120°
- IP Rating: IP20
- PCB: 3oz
- CRI: >80
- Lamp Expectancy: >50000hrs
- Wiring: Parallel
- Dimmable: Yes
- LED Chip Type: 2216
- LEDs per Metre: 180
- Maximum Length: 5000mm
- Cutting Increments: 33mm
- Mounting: Aluminium Profile or Heat Sink
- Operating Temperature: 0 - +60° Celcius
- Ambient Temperature: -20° - +50° Cecius
- Warranty: 3 Years Replacement*
- Sold Per Metre
Dimensions
- Length: 1000mm
- Width: 4mm
- Height: 0.8mm
Click to view technical specifications:
