Description
The HV9783-IP20-120-5K is a high-performance 24W per metre LED Strip designed to deliver bright, consistent 5500K Cool White illumination for premium architectural and decorative lighting applications.
Featuring 120 high-output LEDs per metre, it provides excellent brightness and smooth light distribution, making it ideal for installations requiring powerful linear illumination.
Operating on 24V DC, the flexible strip is perfect for under-cabinet lighting, shelving, joinery, cove lighting, display lighting, retail fit-outs, hospitality venues, commercial spaces, and task lighting applications.
For optimal performance and heat dissipation, it is recommended for use with compatible aluminium LED profiles.
Specifications
- Input Voltage: 12V DC power supply required (not included)
- Wattage: 24W
- Colour Temp: 5500K
- Lumens: 2200lm
- IP Rating: IP20
- Beam Angle: 120°
- PCB: 3oz
- CRI: >80
- Lamp Expectancy: >50000hrs
- Wiring: Parallel
- Dimmable: Yes
- LED Chip Type: 2835
- No. of Chips Per Metre: 120
- Maximum Cut Length: 5000mm
- Cutting Increments: 25mm
- Mounting: Aluminium Profile or Heat Sink
- Operating Temperature: 0 - +60° Celsius
- Ambient Temperature: -20° - +50° Celsius
- Warranty: 3 Years Replacement
- Sold by the Metre
Dimensions
- Length: 1000mm
- Width: 10mm
- Height: 1.1mm
