Description
The HV9734-IP20-240-3K is a compact 14.4W Micro LED Strip designed to provide bright, even illumination in a warm 3000K colour temperature.
Its slim profile makes it ideal for installations where space is limited, including cabinetry, shelving, display lighting and architectural features.
With an IP20 rating, this LED strip is suitable for dry indoor environments and is a practical option for residential, retail and commercial lighting applications.
Specifications
- Input Voltage: 24V DC power supply required (not included)
- Wattage: 19.2W
- Colour Temp: 3000K
- Lumens: 1500lm
- Beam Angle: 120°
- IP Rating: IP20
- PCB: 3oz
- CRI: >80
- Lamp Expectancy: >50000hrs
- Wiring: Parallel
- Dimmable: Yes
- LED Chip Type: 2216
- No. Chips Per Metre: 240
- Maximum Length: 5000mm
- Cutting Increments: 25mm
- Mounting: Aluminium Profile or Heat Sink
- Operating Temperature: 0 - +60° Celcius
- Ambient Temperature: -20° - +50° Celcius
- Warranty: 3 Years Replacement*
- Sold Per Metre
Dimensions
- Length: 1000mm
- Width: 4mm
- Height: 0.8mm
