Description
The Havit HV9654-24V is a 100W IP66-rated, waterproof constant voltage LED driver designed for outdoor, 24V DC lighting, featuring a silver aluminium housing, pre-wired flex and plug for easy installation, and a 3-year replacement warranty.
It operates on 240V AC, supports a 10-80W load range, and includes protection against short circuits and over-temperature.
Specifications
- Input Voltage: 240V
- Output power: 100W
- Output Voltage: 24v DC Constant Voltage
- Recommended Max load: 80w
- Recommended Mini Load: 10w
- IP Rating: IP66
- Wiring: Parallel
- Flex and plug included
- No. of Output Cables: 1
- Protection Class: 1 (Earth Required)
- Protection: Short Circuit, Overload, Over Temperature
- Fixture Colour: Silver
- Material: Aluminium
- Warranty: 3 Years Replacement*
Dimensions
- Height: 44.8mm
- Width: 67.5mm
- Length: 210mm
Click to view technical specification:
