Description
The Havit HV9660-24V100W is a 100W, 24V DC Triac-dimmable LED driver designed for outdoor use, featuring a durable IP66-rated aluminium housing.
It supports 10%–100% dimming with trailing or leading-edge dimmers and comes pre-wired with a flex and plug for easy installation.
Specifications
- Input Voltage: 240V
- Output Voltage: 24v DC Constant Voltage
- Output power: 100W
- Recommended Max load: 80w
- Recommended Mini Load: 10w
- IP Rating: IP66
- Wiring: Parallel
- Flex and plug included
- Protection Class: 1 (Earth Required)
- Protection: Short Circuit, Overload, Over Temperature
- Dimmable: Yes (10%-100%)
- Dimmable with either Trailing or Leading Edge Dimmers
- Fixture Colour: Grey
- Material: Aluminium
- Warranty: 3 Years Replacement*
Dimensions
- Height: 43mm
- Width: 70mm
- Length: 230mm
Click to view technical specification:
