Description
The Havit HV9668-24V100W is a 100W, 24V DC constant voltage, Triac-dimmable indoor LED driver designed for 240V AC input.
It features a white/blue plastic casing, includes a flex and plug for easy installation, has an IP20 rating, and requires a 10W minimum load, with a recommended 80W max load.
Specifications
- Input Voltage: 220 - 240v AC
- Output Voltage: 24v DC Constant Voltage
- Output power: 100W
- Recommended Max load: 80w
- Recommended Mini Load: 10w
- IP Rating: IP20
- Protection Class: 2 (No Earth Required)
- Wiring: Parallel
- Flex and Plug Included
- Protection: Short Circuit, Overload, Over Temperature
- Dimmable: Yes - Triac (5%-100%)
- Fixture Colour: White - Blue
- Material: Plastic
- Warranty: 3 Years Replacement*
Dimensions
- Length: 210mm
- Width: 67mm
- Height: 34mm
